HUATO LUX-UV lumanance Ultraviolet multifunctional datalogging illuminometer
S635 Products introduction
HUATO LUX-UV lumanance Ultraviolet multifunctional datalogging illuminometer is built for the measurement of LED light, it is perfect for the led production line and light manufacturer workshop. The data of temperature, relative humidity, illumination and UV intensity can be simultaneously monitored and stored in it’s memory, the screen can also display the light intensity and ultraviolet intensity. We add a USB interface for users to download the data recorded to a computer.
Features:
Small size, easy to take away for field research.
Can be fixed on wall for fix point monitoring.
Measures illumanance, UV intensity, temperature and relative humidity and records data.
you can manually switch between manual or automatic data record.
Min/Max/Avg Function
Low battery indication
Low Power Consumption
Run on AC or DC power .
Record ability: 43000 groups of data .
communication : USB
Specifications of S635:
| Model | S635-LUX-UV |
| Light measuring | 0~40000Lux |
| Light resolution | 0.1Lux |
| Light accuracy | ±4%rdg |
| Ultraviolet range | 0~1000uW/cm2 |
| Ultraviolet resolution | 0.1uW/cm2 |
| Ultraviolet accuracy | ±10%rdg |
| Temperature measuring range | -40~85℃ |
| Temperature resolution | 0.1℃ |
| Temperature accuracy | ±0.2℃ |
| Humidity measuring range | 0~100%RH |
| Humidity resolution | 0.1%RH |
| Humidity accuracy | ±3%RH |
| Refresh interval | 3~240 seconds adjustable |
| Log interval | 1 minute to 24 hours |
| Record capacity | 4,3000 |
| Battery | 3.6V lithium battery * 2 |
| LCD size | 40mm * 28mm |
| Dimension | 90mm(L) * 68mm(W) * 32mm(H) |
| Accessory | Software CD, USB cable,Operation manual , battery. |
This portable product widely used in electro-optical sources, research teaching, metallurgy building, industry inspection as well as agriculture researching and illumination control.
